CAD CAM Joinery Component Library Software.

Every joinery business has a set of components they build over and over. Door frames. Window sections. Staircase assemblies. Cabinet carcasses. Drawer systems. Screen panels.

Most joinery shops redraw these from scratch every single job. That is time your team cannot afford to waste.

TopSolid Wood lets you build a library of your most-used joinery components and reuse them across every job adjusted for size, material and configuration without starting from scratch.

Build it once. Use it forever.

Change the Size — Everything Updates

Stored components are not static drawings. Change the width of a door frame and the joints, rebates and machining update automatically. Change the material and the toolpaths adjust.

Your team configures. They do not redraw.

Library to CNC — No Extra Steps

Every component in your library carries its machining intelligence with it. Pull a component, size it for the job and the CNC toolpaths are already built in.

No re-programming. No risk of the workshop cutting from the wrong file.

The Time Saving Compounds

A joinery shop producing 15 door frames a week across different jobs — without a library every one starts from a blank screen. With TopSolid Wood every one starts from a proven, machine-ready component.

Multiply that across your full range of repeat work and the numbers add up fast.

Local Support From People Who Know Joinery

TopSolid Wood is available in Australia exclusively through Opticad Solutions. Training is built around your actual components and your actual workflow from day one.

‘Everything we draw in the software can be exported and manufactured. Nothing is required to be drawn again in any other software.’ — Vos Construction and Joinery, Tasmania.

Freqquently Asked Questions:

What joinery components can I store in a TopSolid Wood library?

Any component your shop builds repeatedly — door frames, window sections, staircase assemblies, cabinet carcasses, drawer systems, moulding profiles and commercial fitout components. If your shop builds it more than once, it belongs in your library.

Does changing the size of a stored component mean redrawing it?

No. Components stored in TopSolid Wood are intelligent models, not static drawings. Change the width, height or material and the joints, rebates, toolpaths and cut list all update automatically. Your team configures the component — they do not redraw it.

Does the component library connect directly to our CNC machine?

Yes. Every component in your TopSolid Wood library carries its CNC machining intelligence with it. When you pull a component from the library and size it for a job, the toolpaths are already built in. There is no separate CAM step and no re-programming at the machine.

How do we get our existing joinery components into TopSolid Wood?

Opticad Solutions builds your initial library as part of the setup and training process. Your most-used components are configured in TopSolid Wood to reflect the way your shop actually builds them — so from day one the library is working for your business, not a generic template.
